Specification
| Rating input voltage | 2000 VA / 1200 W |
| Rating input frequency | 60/50Hz (auto sensing) |
| Input phase | Single phase |
| Input socket | With Fuse |
| Cold Start (0 to 100% load) | Press the ON/OFF Switch |
| Input Range (220V) | 140-300 |
| Rating output(VA) | 2000 |
| Rating output (W) | 1200 |
| Power factor | 0.6 |
| Rating output voltage (V) | 220 |
| Waveform | Battery mode (simulated sine wave), AC mode(sine wave) |
| AC Voltage Regulation | ±10% (Battery mode) |
| Rear output socket | 4 x Universal – Battery backup |
| Waveform | Simulated Sine Wave (Battery mode) |
| Line Mode | Synchronize with the utility |
| Rating frequency | 60Hz or 50 Hz ± 1 Hz |
| Battery Mode | Yellow flashing |
| Short circuit protection Line Mode | Fuse & Firmware protection |
| Short circuit protection Battery Mode | Firmware Protection |
| Overload protection Line Mode | 110%±5%; Go to fault mode Line Mode after 5 minutes, 120%±5%; Go to fault mode immediately. |
| Overload protection Battery Mode | 110%±5%; Shutdown after 5 seconds, 120%±5%, Shutdown immediately |
| Indicators AC mode | Green Lighting |
| Indicators Battery Mode | Yellow Flashing |
| Indicators Fault | Red Lighting |
| Alarm Battery Mode | Sounding every 10 Seconds |
| Alarm Low Battery | Sounding every Second |
| Alarm Overload | Sounding every 0.5 second |
| Alarm Fault | Continuously sounding |
| Full Protection | Overload, discharge, and Overcharge protection |
| Transfer Time | Typical 2-6ms, 10ms max. |
| Transfer Time | Typical 2-6ms, 10ms max. |
| Communication Interface | Optional RS232/RJ11 |
| Battery and runtime Rating | 2 X 12V/9AH |
| Recharge time – Typical | 6-8 hours recover to 90% capacity |
| Charge current | About 1A at normal mode. |
| Dimension, W X H X D (cm) | 22.5 X 12.5 X 39 |
| Net Weight (kgs) | 12.7KGS |
| Humidity | 0-90 % RH @ 0- 40°C (non-condensing) |
| Noise Level | Less than 45dB |
| Compatible with OS | Supports Windows® 2000/2003/XP/Vista/2008/7 |
| Communication interface | Elite 2000pro (N/A), Elite 2000ipro (USB/RJ11) |
