D-LinkModel DES-1005D
D-LINK SWITCH 5-PORT SWITCH DES-1005D
In stock
D-LINK SWITCH 5-PORT SWITCH DES-1005D
At a glance
- Pallet gross width
- 120 cm
- Pallet gross length
- 110 cm
- Harmonized System (HS) code
- 85176990
- Manual
- Yes
- Cables included
- AC
- User guide
- Yes
Request a quote for pricing
Answered within one business day. Volume pricing available.
Nationwide delivery, installed in Lagos. Lead times Manufacturer warranty, claims handled by us. How it works Authorised reseller, SON certified. Quotes answered within one business day.
Overview
D-LINK SWITCH 5-PORT SWITCH DES-1005D
Specifications
| Pallet gross width | 120 cm |
|---|---|
| Pallet gross length | 110 cm |
| Harmonized System (HS) code | 85176990 |
| Manual | Yes |
|---|---|
| Cables included | AC |
| User guide | Yes |
| Shipping (inner) case height | 23 cm |
|---|---|
| Shipping (inner) case width | 35 cm |
| Shipping (inner) case length | 51.5 cm |
| Shipping (inner) case net weight | 8.5 kg |
| Products per shipping (inner) case | 50 pc(s) |
| Pallet gross weight (air) | 465.2 kg |
| Master (outer) cases per pallet (air) | 48 pc(s) |
| Products per pallet (air) | 2400 pc(s) |
| Pallet height (air) | 197.5 cm |
| Pallet gross weight (sea) | 465.2 kg |
| Master (outer) cases per pallet (sea) | 48 pc(s) |
| Products per pallet (sea) | 2400 pc(s) |
| Pallet height (sea) | 197.5 cm |
| Shipping (inner) case gross weight | 9.25 kg |
| Auto MDI/MDI-X | Yes |
|---|
| Width | 125.3 mm |
|---|---|
| Depth | 83.4 mm |
| Height | 29.1 mm |
| Package width | 65 mm |
|---|---|
| Package depth | 105 mm |
| Package height | 98 mm |
| Package weight | 170 g |
| Operating temperature (T-T) | 0 - 50 °C |
|---|---|
| Storage temperature (T-T) | -10 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Plug and Play | Yes |
|---|---|
| LED indicators | LAN, Power |
| Power consumption (typical) | 2.5 W |
|---|---|
| Power over Ethernet (PoE) | No |
| Power LED | Yes |
| Heat dissipation | 8.528 BTU/h |
|---|
| Maximum data transfer rate | 0.2 Gbit/s |
|---|---|
| Switch type | Unmanaged |
| Supported data transfer rates | 10/20/100/200 Mb/s |
| Packet transfer speed | 14880 - 148800 p/s |
| Certification | RoHS, FCC, CE |
| Stackable | No |
|---|---|
| Product colour | Black |
| Rack mounting | No |
| MAC address table | 2000 entries |
|---|---|
| Switching capacity | 1 Gbit/s |
| Forwarding rate | 0.1488 Mpps |
| Store-and-forward | Yes |
| Packet buffer memory | 0.046875 MB |
| 10G support | No |
|---|---|
| Networking standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3x |
| Copper ethernet cabling technology | 100Base-TX, 10Base-T |
| Cable types supported | Cat3, Cat4, Cat5, Cat5e |
| Full duplex | Yes |
| Flow control support | Yes |
| Auto-negotiation | Yes |
| MAC address auto-learning supported | Yes |
| Basic switching RJ-45 Ethernet ports quantity | 5 |
|---|---|
| Basic switching RJ-45 Ethernet ports type | Fast Ethernet (10/100) |
| Installed SFP modules quantity | 0 |
| Installed SFP+ modules quantity | 0 |
| Power connector | DC-in jack |
Warranty
5 years
