Epson EH-LS9000B
EpsonModel V11HC13180
Image 1 of 5
Available on lead time
Request a quote for pricing
We respond within one business day. Volume pricing available.
Nationwide delivery, installed in Lagos. Lead times Manufacturer warranty, claims handled by us. How it works Authorised reseller, certified by the Standards Organisation of Nigeria. Buying in volume? Send the schedule and we price the whole list.
At a glance
- Security features
- Kensington lock
- Other features
- A/V mute, Direct Power on/off, Frame interpolation, Horizontal and vertical keystone correction, Lens position memory, Long light source life, Quick Corner, Super resolution
- Video colour modes
- Bright cinema, Cinema, Dynamic, Natural, Vivid
- Ethernet LAN data rates
- 10,100 Mbit/s
Overview
Epson EH-LS9000B is a Epson projectors & screen with a power consumption of 302 Watt (Normal On-Mode), 198 Watt (Eco On-Mode), 0.4 Watt (Energy saving standby) and a control panel of 0.74 inch. The details below are drawn from the manufacturer specification and are what to check against your own requirement before requesting a quote.
Power consumption is 302 Watt (Normal On-Mode), 198 Watt (Eco On-Mode), 0.4 Watt (Energy saving standby). Control panel is 0.74 inch. Option type is Air filter, Ceiling mount, Safety wire set, Suspension adapter. Products per pallet layer is 2 pc(s). Products per pallet is 14 pc(s). Country of origin is Philippines. Supported network protocols is ESC/VP.net, PJLink. Audio Return Channel (ARC) is Yes. Each of these is listed again in the specification table, so nothing here has to be taken on trust.
Warranty: 60 months Carry in or 12,000 h. Ask us if you need a different configuration - we quote against the specification you actually need rather than the one on the box.
Specifications
| Security features | Kensington lock |
|---|---|
| Other features | A/V mute, Direct Power on/off, Frame interpolation, Horizontal and vertical keystone correction, Lens position memory, Long light source life, Quick Corner, Super resolution |
| Video colour modes | Bright cinema, Cinema, Dynamic, Natural, Vivid |
| Ethernet LAN data rates | 10,100 Mbit/s |
| Ethernet LAN (RJ-45) ports | 1 |
| Option type | Air filter, Ceiling mount, Safety wire set, Suspension adapter |
| Control panel | 0.74 inch |
| Products per pallet layer (UK) | 2 pc(s) |
|---|---|
| Products per pallet (UK) | 14 pc(s) |
| Country of origin | Philippines |
| Products per pallet | 14 pc(s) |
| Products per pallet layer | 2 pc(s) |
| Power consumption | 302 Watt (Normal On-Mode), 198 Watt (Eco On-Mode), 0.4 Watt (Energy saving standby) |
|---|
| Market positioning | Home cinema |
|---|---|
| Product colour | Black |
| Built-in display | No |
| Placement | Ceiling, Desktop |
| Quantity per pack | 1 pc(s) |
|---|
| Power consumption (economy mode) | 198 W |
|---|---|
| Power consumption (typical) | 302 W |
| Power consumption (PowerSave) | 0.4 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power source | AC |
| Width | 520 mm |
|---|---|
| Depth | 447 mm |
| Height | 193 mm |
| Weight | 12.7 kg |
| Package width | 555 mm |
|---|---|
| Package depth | 700 mm |
| Package height | 270 mm |
| Package weight | 17 kg |
| Operating temperature (T-T) | 5 - 35 °C |
|---|---|
| Storage temperature (T-T) | -10 - 60 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 10 - 90% |
| Cable lock slot | Yes |
|---|---|
| Cable lock slot type | Kensington |
| Built-in speaker(s) | No |
|---|
| Interactive | No |
|---|---|
| Noise level (economic mode) | 22 dB |
| Preset modes | Cinema, Dynamic |
| Noise level | 30 dB |
| Native aspect ratio | 16:9 |
|---|---|
| Contrast ratio (typical) | 1800:1 |
| Contrast ratio (dynamic) | 2500000:1 |
| Vertical scan range | 384 - 480 Hz |
| High Dynamic Range (HDR) supported | Yes |
| High Dynamic Range (HDR) technology | High Dynamic Range 10 (HDR10), High Dynamic Range 10+ (HDR10 Plus), Hybrid Log-Gamma (HLG) |
| 3D | No |
| Heat dissipation | 1026.8 BTU/h |
| Card reader integrated | No |
|---|
| Smart TV | No |
|---|---|
| Ethernet LAN | Yes |
| Supported network protocols | ESC/VP.net, PJLink |
| Interface | USB 2.0 Type B (Service Only), Powered USB (2x), RS-232C, Ethernet interface (100 Base-TX / 10 Base-T), Trigger out, HDMI ARC, HDMI (HDCP 2.3) |
|---|---|
| VGA (D-Sub) ports quantity | 0 |
| DVI port | No |
| HDMI ports quantity | 0 |
| HDCP | Yes |
| Service port type | USB Type-B |
| Serial interface type | RS-232C |
| Wi-Fi | No |
| Audio Return Channel (ARC) | Yes |
| Analog signal format system | Not supported |
|---|---|
| Full HD | Yes |
| Video processing | 10 bit |
| Colour modes (2D) | Bright cinema, Cinema, Dynamic, Natural, Vivid |
| Focus | Motorized |
|---|---|
| Aperture range (F-F) | 2 - 3 |
| Zoom capability | Yes |
| Zoom ratio | 2.1:1 |
| Throw ratio | 1.35 - 2.84:1 |
| Focal length range | 22.5 - 46.7 mm |
| Horizontal lens shift range | -24 - -24% |
| Vertical lens shift range | -96.3 - -96.3% |
| Lens position memory | 10 |
| Light source type | Laser |
|---|---|
| Service life of light source | 20000 h |
| Service life of light source (economic mode) | 20000 h |
| Projector brightness | 2200 ANSI lumens |
|---|---|
| Projection technology | 3LCD |
| Projector native resolution | UHD 4K (3840x2160) |
| Smart projector | No |
| Screen size compatibility | 1270 - 7620 mm (50 - 300") |
| Projection distance | 3 - 6.3 m |
| Projection distance (wide) | 3 - 6.3 m |
| Number of colours | 1.07 billion colours |
| Projector brightness (economic mode) | 1000 ANSI lumens |
| Keystone correction, vertical | ±30° |
| Keystone correction, horizontal | ±30° |
| Matrix size | 1.88 cm (0.74") |
| Vertical synchronization (min) | 0.384 kHz |
| Vertical synchronization (max) | 0.48 kHz |
Warranty
60 months Carry in or 12,000 h
