Epson PowerLite L690SU Short throw projector 6200 ANSI lumens 3LCD WUXGA (1920x1200) White
EpsonModel V11HB31020
Image 1 of 5
Available on lead time
Request a quote for pricing
We respond within one business day. Volume pricing available.
Nationwide delivery, installed in Lagos. Lead times Manufacturer warranty, claims handled by us. How it works Authorised reseller, certified by the Standards Organisation of Nigeria. Buying in volume? Send the schedule and we price the whole list.
At a glance
- Warranty period
- 3 year(s)
- Video colour modes
- Cinema, DICOM simulation mode, Dynamic, Multi-projection, Natural, Presentation
- Ethernet LAN data rates
- 10,100 Mbit/s
- Market positioning
- Education
Overview
Epson PowerLite L690SU Short throw projector 6200 ANSI lumens 3LCD WUXGA (1920x1200) White is a Epson projectors & screen with a warranty period of 3 year(s) and a supported network protocols of HTTPS, SNMP, ESC/VP.net, PJLink. The details below are drawn from the manufacturer specification and are what to check against your own requirement before requesting a quote.
Warranty period is 3 year(s). Supported network protocols is HTTPS, SNMP, ESC/VP.net, PJLink. Apple AirPlay 2 support is Yes. Ethernet LAN data rates is 10,100 Mbit/s. Keystone correction, vertical is -30 - 30°. Video colour modes is Cinema, DICOM simulation mode, Dynamic, Multi-projection, Natural, Presentation. Keystone correction, horizontal is -30 - 30°. Vertical lens shift range is -50 - 50%. Each of these is listed again in the specification table, so nothing here has to be taken on trust.
Specifications
| Warranty period | 3 year(s) |
|---|
| Video colour modes | Cinema, DICOM simulation mode, Dynamic, Multi-projection, Natural, Presentation |
|---|---|
| Ethernet LAN data rates | 10,100 Mbit/s |
| Market positioning | Education |
|---|---|
| Product type | Short throw projector |
| Product colour | White |
| Built-in display | Yes |
| Placement | Ceiling, Desktop |
| Display | LCD |
| Batteries included | Yes |
|---|---|
| Cables included | Power |
| Remote control included | Yes |
| Power consumption (economy mode) | 233 W |
|---|---|
| Power consumption (typical) | 336 W |
| Power consumption (standby) | 0.4 W |
| Power consumption (max) | 399 W |
| AC input frequency | 50/60 Hz |
| Power source | AC |
| AC adapter output voltage | 100 - 240 V |
| Width | 440 mm |
|---|---|
| Depth | 362 mm |
| Height | 151 mm |
| Weight | 8.9 kg |
| Storage temperature (T-T) | -10 - 60 °C |
|---|---|
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 10 - 90% |
| Cable lock slot | Yes |
|---|---|
| Cable lock slot type | Kensington |
| On Screen Display (OSD) | Yes |
| Built-in speaker(s) | Yes |
|---|
| Interactive | No |
|---|---|
| Noise level (economic mode) | 25 dB |
| Preset modes | Cinema, Dynamic, Presentation |
| Noise level | 34 dB |
| Card reader integrated | No |
|---|---|
| HDCP version | 2.3 |
| Display diagonal | 1.7 cm (0.67") |
|---|---|
| Native aspect ratio | 16:10 |
| Contrast ratio (typical) | 5000000:1 |
| 3D | No |
| Password protection | Yes |
|---|
| Ethernet LAN | Yes |
|---|---|
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Miracast | Yes |
| Supported network protocols | HTTPS, SNMP, ESC/VP.net, PJLink |
| Apple AirPlay 2 support | Yes |
| Analog signal format system | Not supported |
|---|---|
| Full HD | Yes |
| VGA (D-Sub) ports quantity | 0 |
|---|---|
| DVI port | No |
| HDMI ports quantity | 2 |
| HDCP | Yes |
| HDBaseT port | Yes |
| USB 2.0 Type-A ports quantity | 2 |
| USB 2.0 Type-B ports quantity | 1 |
| Serial interface type | RS-232C |
| RS-232C | Yes |
| Wi-Fi | Yes |
| USB 2.0 ports quantity | 3 |
| RMS rated power | 10 W |
|---|
| Focus | Manual |
|---|---|
| Aperture range (F-F) | 1.7 - 2.1 |
| Zoom capability | Yes |
| Zoom type | Manual |
| Zoom ratio | 1.2:1 |
| Throw ratio | 0.79 - 1.36:1 |
| Focal length range | 11.6 - 19.9 mm |
| Horizontal lens shift range | -20 - 20% |
| Vertical lens shift range | -50 - 50% |
| Light source type | Laser |
|---|---|
| Service life of light source | 20000 h |
| Service life of light source (economic mode) | 30000 h |
| Projector brightness | 6200 ANSI lumens |
|---|---|
| Projection technology | 3LCD |
| Projector native resolution | WUXGA (1920x1200) |
| Supported aspect ratios | 16:10, 16:6, 21:9 |
| Screen size compatibility | 1524 - 10160 mm (60 - 400") |
| Projection distance | 1.02 - 11.89 m |
| Projection distance (wide) | 1 - 7 m |
| Projection distance (tele) | 1.8 - 11.9 m |
| Number of colours | 1.07 billion colours |
| Projector brightness (economic mode) | 4340 ANSI lumens |
| Keystone correction, vertical | -30 - 30° |
| Keystone correction, horizontal | -30 - 30° |
