Lenovo ThinkSmart SmartDock Wired USB 3.2 Gen 2 (3.1 Gen 2) Type-C Black
LenovoModel 40BN0135EU
Image 1 of 5
Available on lead time
Request a quote for pricing
We respond within one business day. Volume pricing available.
Nationwide delivery, installed in Lagos. Lead times Manufacturer warranty, claims handled by us. How it works Authorised reseller, certified by the Standards Organisation of Nigeria. Buying in volume? Send the schedule and we price the whole list.
At a glance
- Ethernet LAN data rates
- 100,1000 Mbit/s
- Ethernet LAN (RJ-45) ports
- 1
- Certification
- FCC/ICES CE RCM BSMI VCCI CB cULus TUV- Mark LoA UKCA
- Width
- 257.6 mm
Overview
Lenovo ThinkSmart SmartDock Wired USB 3.2 Gen 2 (3.1 Gen 2) Type-C Black is a Lenovo switches & adapter with a certification of FCC/ICES CE RCM BSMI VCCI CB cULus TUV- Mark LoA UKCA and a ethernet lan (rj-45) ports of 1. The details below are drawn from the manufacturer specification and are what to check against your own requirement before requesting a quote.
Certification is FCC/ICES CE RCM BSMI VCCI CB cULus TUV- Mark LoA UKCA. Ethernet LAN (RJ-45) ports is 1. Ethernet LAN data rates is 100,1000 Mbit/s. USB Power Delivery (USB PD) is Yes. DC-in jack is Yes. Weight is 2.6 kg. Height is 49.5 mm. Depth is 164 mm. Each of these is listed again in the specification table, so nothing here has to be taken on trust.
Warranty: 3 Years. Ask us if you need a different configuration - we quote against the specification you actually need rather than the one on the box.
Specifications
| Ethernet LAN data rates | 100,1000 Mbit/s |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Certification | FCC/ICES CE RCM BSMI VCCI CB cULus TUV- Mark LoA UKCA |
| Width | 257.6 mm |
|---|---|
| Depth | 164 mm |
| Height | 49.5 mm |
| Weight | 2.6 kg |
| Package width | 677 mm |
|---|---|
| Package depth | 389 mm |
| Package height | 95 mm |
| Package weight | 3.8 kg |
| Operating temperature (T-T) | 0 - 35 °C |
|---|---|
| Operating relative humidity (H-H) | 20 - 95% |
| VESA mounting | Yes |
|---|---|
| Cable lock slot | Yes |
| Ethernet LAN | Yes |
|---|
| Brand compatibility | Lenovo |
|---|---|
| Host interface | USB 3.2 Gen 2 (3.1 Gen 2) Type-C |
| Power consumption (max) | 135 W |
|---|---|
| Power source type | AC |
| USB Power Delivery (USB PD) | Yes |
| Maximum refresh rate | 60 Hz |
|---|
| Card reader integrated | No |
|---|---|
| Maximum digital resolution | 3840 x 2160 pixels |
| Product colour | Black |
|---|
| Connectivity technology | Wired |
|---|---|
| HDMI ports quantity | 1 |
| DisplayPorts quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| Combo headphone/mic port | Yes |
| USB 2.0 ports quantity | 2 |
| Microphone in | No |
| DC-in jack | Yes |
| Number of displays supported | 2 |
|---|---|
| Maximum VESA mount | 75 x 75 mm |
Warranty
3 Years
