Lenovo TP USB-C Dock-MX Wired USB 3.2 Gen 1 (3.1 Gen 1) Type-C Black
LenovoModel 40AY0090MX
Image 1 of 5
Available on lead time
Request a quote for pricing
We respond within one business day. Volume pricing available.
Nationwide delivery, installed in Lagos. Lead times Manufacturer warranty, claims handled by us. How it works Authorised reseller, certified by the Standards Organisation of Nigeria. Buying in volume? Send the schedule and we price the whole list.
At a glance
- Harmonized System (HS) code
- 84733020
- Windows operating systems supported
- Windows 10, Windows 7
- On/off switch
- Yes
- Compliance certificates
- CE
Overview
Lenovo TP USB-C Dock-MX Wired USB 3.2 Gen 1 (3.1 Gen 1) Type-C Black is a Lenovo switches & adapter with a power connector of USB Type-C and a certification of FCC/ICES CE KCC RCM BSMI VCCI CB cULus EAC TUV- Mark Serbia Kvalitet LoA Israel SII Ukraine DoC NOM. The details below are drawn from the manufacturer specification and are what to check against your own requirement before requesting a quote.
Power connector is USB Type-C. Certification is FCC/ICES CE KCC RCM BSMI VCCI CB cULus EAC TUV- Mark Serbia Kvalitet LoA Israel SII Ukraine DoC NOM. Harmonized System (HS) code is 84733020. Ethernet LAN (RJ-45) ports is 1. Ethernet LAN data rates is 10,100,1000 Mbit/s. Compliance certificates is CE. Power supply is 90 W. Weight is 388 g. Each of these is listed again in the specification table, so nothing here has to be taken on trust.
Warranty: 3 Years. Ask us if you need a different configuration - we quote against the specification you actually need rather than the one on the box.
Specifications
| Harmonized System (HS) code | 84733020 |
|---|
| Windows operating systems supported | Windows 10, Windows 7 |
|---|
| On/off switch | Yes |
|---|---|
| Compliance certificates | CE |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet LAN (RJ-45) ports | 1 |
| Certification | FCC/ICES CE KCC RCM BSMI VCCI CB cULus EAC TUV- Mark Serbia Kvalitet LoA Israel SII Ukraine DoC NOM |
| Quantity per pack | 1 pc(s) |
|---|---|
| Cables included | USB Type-C |
| Width | 171 mm |
|---|---|
| Depth | 80 mm |
| Height | 30.8 mm |
| Weight | 388 g |
| Package width | 210 mm |
|---|---|
| Package depth | 158 mm |
| Package height | 75 mm |
| Package weight | 955 g |
| Operating temperature (T-T) | 0 - 35 °C |
|---|---|
| Operating relative humidity (H-H) | 20 - 95% |
| Cable lock slot | Yes |
|---|---|
| Cable lock slot type | Kensington |
| Ethernet LAN | Yes |
|---|
| Host interface | USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
|---|
| Power source type | USB |
|---|---|
| Power supply | 90 W |
| HD type | 4K Ultra HD |
|---|
| Card reader integrated | No |
|---|---|
| Maximum digital resolution | 3840 x 2160 pixels |
| Product colour | Black |
|---|
| Connectivity technology | Wired |
|---|---|
| HDMI ports quantity | 1 |
| DisplayPorts quantity | 2 |
| Headphone outputs | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
| Combo headphone/mic port | Yes |
| USB 2.0 ports quantity | 2 |
| Microphone in | No |
| Power connector | USB Type-C |
| Number of displays supported | 3 |
|---|
Warranty
3 Years
