TP-Link Archer 5G AX1800 Wireless Dual-Band Gigabit Router
TP-LinkModel ARCHER NX200
Image 1 of 5
Available on lead time
Request a quote for pricing
We respond within one business day. Volume pricing available.
Nationwide delivery, installed in Lagos. Lead times Manufacturer warranty, claims handled by us. How it works Authorised reseller, certified by the Standards Organisation of Nigeria. Buying in volume? Send the schedule and we price the whole list.
At a glance
- Country of origin
- China
- Customs product code (TARIC)
- 8517620000
- Cables included
- LAN (RJ-45)
- Quick installation guide
- Yes
Overview
TP-Link Archer 5G AX1800 Wireless Dual-Band Gigabit Router is a TP-Link routers & access point with a customs product code (taric) of 8517620000 and a country of origin of China. The details below are drawn from the manufacturer specification and are what to check against your own requirement before requesting a quote.
Customs product code (TARIC) is 8517620000. Country of origin is China. Browser supported is Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser. Supported network protocols is IPv4, IPv6. Ethernet LAN (RJ-45) ports is 3. Ethernet LAN data rates is 10,100,1000 Mbit/s. MU-MIMO technology is Yes. WPS push button is Yes. Each of these is listed again in the specification table, so nothing here has to be taken on trust.
Specifications
| Country of origin | China |
|---|---|
| Customs product code (TARIC) | 8517620000 |
| Cables included | LAN (RJ-45) |
|---|---|
| Quick installation guide | Yes |
| Windows operating systems supported | Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP |
|---|---|
| Mac operating systems supported | Yes |
| Linux operating systems supported | Yes |
| AC adapter included | Yes |
|---|---|
| On/off switch | Yes |
| Compliance certificates | CE, RoHS |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Ethernet LAN (RJ-45) ports | 3 |
| Antenna design | Internal |
|---|---|
| Antennas quantity | 10 |
| Detachable antenna(s) | Yes |
| DHCP client | Yes |
|---|---|
| DHCP server | Yes |
| USB port | No |
|---|
| Firewall | Yes |
|---|---|
| Firewall security | IPv4 SPI Firewall, IPv6 Firewal |
| DoS attack prevention | Yes |
| Parental control | Yes |
| DMZ support | Yes |
| Access Control List (ACL) | Yes |
|---|---|
| Wi-Fi Multimedia (WMM)/(WME) | Yes |
| Quality of Service (QoS) support | Yes |
| Reset button | Yes |
| WPS push button | Yes |
| MU-MIMO technology | Yes |
| Mobile network generation | 5G |
|---|---|
| 3G standards | DC-HSDPA, HSPA, HSPA+, UMTS |
| 4G standard | LTE-TDD & LTE-FDD |
| 4G bands supported | 700,800,850,900,1500,1800,2100,2300,2500,2600,3500,3700 MHz |
| 5G bands supported | 700,800,850,900,1800,2100,2300,2500,2600,3500,3700 MHz |
| Wi-Fi band | Dual-band (2.4 GHz / 5 GHz) |
|---|---|
| WLAN data transfer rate (max) | 1800 Mbit/s |
| WLAN data transfer rate (first band) | 574 Mbit/s |
| WLAN data transfer rate (second band) | 1201 Mbit/s |
| Ethernet WAN | Yes |
|---|---|
| SIM card slot | Yes |
| WAN connection type | RJ-45 |
| Width | 99 mm |
|---|---|
| Depth | 190 mm |
| Height | 99 mm |
| Weight | 610 g |
| Package width | 230 mm |
|---|---|
| Package depth | 115 mm |
| Package height | 221 mm |
| Package weight | 1.19 kg |
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| AC input voltage | 100 - 240 V |
|---|---|
| Power source type | AC |
| AC input frequency | 50/60 Hz |
| Output current | 2 A |
| Output voltage | 12 V |
| Product type | Tabletop router |
|---|---|
| Product colour | White |
| Ethernet LAN interface type | Gigabit Ethernet |
|---|---|
| Ethernet LAN | Yes |
| Networking standards | IEEE 802.11ax, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| SIM card type | NanoSIM |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Port triggering | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Dynamic DNS (DDNS) | Yes |
| Number of guest networks (2.4 GHz) | 1 |
| Number of guest networks (5 GHz) | 1 |
| 3G bands supported | 850,900,2100 MHz |
| Security algorithms | 64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK |
| VPN support | PPTP VPN, IPSec VPN , OpenVPN |
| Supported network protocols | IPv4, IPv6 |
| Browser supported | Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser |
|---|
