TP-Link InSight S325 Bullet IP security camera Outdoor 1920 x 1080 pixels Ceiling/Wall/Pole
TP-LinkModel INSIGHT S325(2.8MM)
Image 1 of 4
Available on lead time
Request a quote for pricing
We respond within one business day. Volume pricing available.
Nationwide delivery, installed in Lagos. Lead times Manufacturer warranty, claims handled by us. How it works Authorised reseller, certified by the Standards Organisation of Nigeria. Buying in volume? Send the schedule and we price the whole list.
At a glance
- Compliance certificates
- BSMI, CE, Federal Communications Commission (FCC), KC, VCCI
- Ethernet LAN (RJ-45) ports
- 1
- Diameter
- 7.4 cm
- Length
- 169.8 mm
Overview
TP-Link InSight S325 Bullet IP security camera Outdoor 1920 x 1080 pixels Ceiling/Wall/Pole is a TP-Link cctv camera with a supported network protocols of TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP, SMTP, SNMP and a ethernet lan (rj-45) ports of 1. The details below are drawn from the manufacturer specification and are what to check against your own requirement before requesting a quote.
Supported network protocols is TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP, SMTP, SNMP. Ethernet LAN (RJ-45) ports is 1. Number of Privacy masking areas is 4. Noise reduction is Yes. Camera shutter speed is 1/3 - 1/10000 s. International Protection (IP) code is IP67. Signal-to-Noise Ratio (SNR) is 52 dB. Compliance certificates is BSMI, CE, Federal Communications Commission (FCC), KC, VCCI. Each of these is listed again in the specification table, so nothing here has to be taken on trust.
Warranty: 3 year limited warranty. Ask us if you need a different configuration - we quote against the specification you actually need rather than the one on the box.
Specifications
| Compliance certificates | BSMI, CE, Federal Communications Commission (FCC), KC, VCCI |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| Diameter | 7.4 cm |
|---|---|
| Length | 169.8 mm |
| Weight | 353 g |
| Ethernet interface type | Fast Ethernet |
|---|---|
| Ethernet LAN | Yes |
| Supported network protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP, SMTP, SNMP |
| Operating temperature (T-T) | -30 - 60 °C |
|---|---|
| Storage temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Supported graphics resolutions | 320 x 240, 352 x 288, 640 x 360, 640 x 480 (VGA), 704 x 576, 848 x 480, 1280 x 720 (HD 720), 1280 x 960, 1920 x 1080 (HD 1080) |
|---|
| Type | IP security camera |
|---|---|
| Angle of rotation | 360° |
| Placement supported | Outdoor |
| Maximum resolution | 1920 x 1080 pixels |
|---|
| Web browser | Yes |
|---|---|
| Cloud-managed | Yes |
| Connectivity technology | Wired |
|---|---|
| Wi-Fi | No |
| Bluetooth | No |
| Power source type | DC, PoE |
|---|---|
| DC output voltage | 12 |
| IP address filtering | Yes |
|---|---|
| Password protection | Yes |
| Video motion detection | Yes |
| Active tampering alarm | Yes |
| HTTPS encryption | Yes |
| Privacy protection | Yes |
| Intelligent Video Surveillance (IVS) system features | Human detection, Intrusion, Line crossing detection, Region entrance detection, Region exiting detection, Vehicle detection |
| Digest authentication | Yes |
| Built-in HDD | No |
|---|
| Noise reduction | Yes |
|---|
| Built-in microphone | Yes |
|---|---|
| Signal-to-Noise Ratio (SNR) | 52 dB |
| Video compression formats | H.264, H.264+, H.265, H.265+ |
|---|---|
| Video streaming | Yes |
| Noise reduction technology | 3D noise reduction |
| Bit rate control | Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Bit rate | Main Stream: 256 Kbps - 4 Mbps; Sub-Stream: 64 Kbps - 512 Kbps |
| Back Light Compensation (BLC) | Yes |
| Highlight Compensation (HLC) | Yes |
| Smart IR | Yes |
| Digital Wide Dynamic Range (DWDR) | Yes |
| Night vision | Yes |
|---|---|
| Night vision distance | 30 m |
| LED type | IR/White |
| Infra-red wavelength | 850 nm |
| Number of lenses | 1 |
|---|---|
| Detect distance | 47 m |
| Observe distance | 19 m |
| Recognize distance | 9 m |
| Maximum aperture number | 2 |
| Identify distance | 5 m |
| Fixed focal length | 2.8 mm |
| Optical sensor size | 25.4 / 3 mm (1 / 3") |
|---|---|
| Progressive scan | Yes |
| Minimum illumination | 0.005 lx |
|---|---|
| Total megapixels | 2 MP |
| Lens viewing angle, horizontal | 98.8° |
| Lens viewing angle, vertical | 53.5° |
| Lens viewing angle, diagonal | 117° |
| Camera shutter speed | 1/3 - 1/10000 s |
| Number of Privacy masking areas | 4 |
| Number of cameras | 1 |
|---|---|
| Sensor type | CMOS |
| Infrared (IR) cut-off filter | Yes |
| Pan range | 0 - 360° |
|---|---|
| Tilt angle range | 0 - 90° |
| Mounting type | Ceiling/Wall/Pole |
|---|
| Product colour | White |
|---|---|
| Housing material | Metal |
| Form factor | Bullet |
| International Protection (IP) code | IP67 |
Warranty
3 year limited warranty
