TP-Link Omada 5-Port Gigabit Smart Switch with 1-Port PoE++ In and 4-Port PoE+ Out
TP-LinkModel SG2005P-PD(UN)
Image 1 of 4
Available on lead time
Request a quote for pricing
We respond within one business day. Volume pricing available.
Nationwide delivery, installed in Lagos. Lead times Manufacturer warranty, claims handled by us. How it works Authorised reseller, certified by the Standards Organisation of Nigeria. Buying in volume? Send the schedule and we price the whole list.
At a glance
- Compliance certificates
- CE, RoHS
- Switch type
- Managed
- Sustainability compliance
- Yes
- Width
- 170 mm
Overview
TP-Link Omada 5-Port Gigabit Smart Switch with 1-Port PoE++ In and 4-Port PoE+ Out is a TP-Link switches & adapter with a sustainability compliance of Yes and a mib support of Y. The details below are drawn from the manufacturer specification and are what to check against your own requirement before requesting a quote.
Sustainability compliance is Yes. MIB support is Y. IPv4 & IPv6 features is Dual stack IPv4/IPv6, IPv4/IPv6 access-control list (ACL), IPv6 tracert. Number of VLANs is 4000. Virtual LAN features is Voice VLAN. Packet buffer memory is 4.1 MB. Compliance certificates is CE, RoHS. Heat dissipation is 243.99 BTU/h. Each of these is listed again in the specification table, so nothing here has to be taken on trust.
Warranty: 3 year limited warranty for normal product and 5 year warranty for managed switch. Ask us if you need a different configuration - we quote against the specification you actually need rather than the one on the box.
Specifications
| Compliance certificates | CE, RoHS |
|---|---|
| Switch type | Managed |
| Sustainability compliance | Yes |
|---|
| Width | 170 mm |
|---|---|
| Depth | 100 mm |
| Height | 38.5 mm |
| Operating temperature (T-T) | -40 - 60 °C |
|---|---|
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| LED indicators | Yes |
|---|
| Heat dissipation | 243.99 BTU/h |
|---|
| Power over Ethernet (PoE) power per port | 64 W |
|---|
| Power consumption (typical) | 71.5 W |
|---|---|
| Power supply included | Yes |
| Power source | DC/PoE |
| Power over Ethernet (PoE) | Yes |
| Stackable | No |
|---|---|
| Product colour | White |
| Rack mounting | No |
| Form factor | Desktop |
| IPv4 & IPv6 features | Dual stack IPv4/IPv6, IPv4/IPv6 access-control list (ACL), IPv6 tracert |
|---|
| Multicast support | Yes |
|---|---|
| Multicast MAC address table | 8000 entries |
| IPv4 multicast entries | 511 |
| IPv6 multicast entries | 511 |
| IP-MAC-Port binding | Yes |
|---|---|
| MAC address filtering | Yes |
| DHCP features | DHCP relay, DHCP server |
| Access Control List (ACL) IPv4 entries | 32 |
| Password protection | Yes |
| IGMP snooping | Yes |
| Authentication | MAC-based authentication, Port-based authentication |
| MAC address table | 8000 entries |
|---|---|
| Switching capacity | 10 Gbit/s |
| Jumbo frames support | Yes |
| Jumbo frames | 9 |
| Packet forwarding rate (1 Gbps) | 7440 pps |
| Packet buffer memory | 4.1 MB |
| 10G support | Yes |
|---|---|
| VLAN support | Yes |
| Networking standards | IEEE 802.11d, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 100BASE-T |
| Cable types supported | Cat5, Cat5e |
| Port mirroring | Yes |
| Security algorithms | 802.1x RADIUS |
| Flow control support | Yes |
| Link aggregation | Yes |
| Spanning tree protocol | Yes |
| IPv4 routes | 32 |
| IPv6 routes | 32 |
| Virtual LAN features | Voice VLAN |
| Number of VLANs | 4000 |
| Basic switching RJ-45 Ethernet ports quantity | 4 |
|---|---|
| Basic switching RJ-45 Ethernet ports type | 10G Ethernet (100/1000/10000) |
| 10G Ethernet (copper) ports quantity | 4 |
| Web-based management | Yes |
|---|---|
| Access Control List (ACL) | Yes |
| Switch layer | L2/L2+ |
| Cloud-managed | Yes |
| Quality of Service (QoS) support | Yes |
| ARP inspection | Yes |
| MIB support | Y |
Warranty
3 year limited warranty for normal product and 5 year warranty for managed switch
