TP-Link Omada 8-Port 2.5GBASE-T and 2-Port 10GE SFP+ Smart Switch with 8-Port PoE+
TP-LinkModel SG2210XMP-M2(UN)
Image 1 of 5
Available on lead time
Request a quote for pricing
We respond within one business day. Volume pricing available.
Nationwide delivery, installed in Lagos. Lead times Manufacturer warranty, claims handled by us. How it works Authorised reseller, certified by the Standards Organisation of Nigeria. Buying in volume? Send the schedule and we price the whole list.
At a glance
- Compliance certificates
- CE, Federal Communications Commission (FCC), RoHS
- Switch type
- Managed
- Ethernet LAN data rates
- 10,100,1000,2500 Mbit/s
- Product colour
- Black
Overview
TP-Link Omada 8-Port 2.5GBASE-T and 2-Port 10GE SFP+ Smart Switch with 8-Port PoE+ is a TP-Link switches & adapter with a sustainability compliance of Yes and a power connector of DC-in jack. The details below are drawn from the manufacturer specification and are what to check against your own requirement before requesting a quote.
Sustainability compliance is Yes. Power connector is DC-in jack. MIB support is Y. Ethernet LAN data rates is 10,100,1000,2500 Mbit/s. Number of VLANs is 4000. Virtual LAN features is Protocol-based VLAN, Tagged VLAN, Voice VLAN. Reset button is Yes. Packet buffer memory is 12 MB. Each of these is listed again in the specification table, so nothing here has to be taken on trust.
Warranty: 3 year limited warranty for normal product and 5 year warranty for managed switch. Ask us if you need a different configuration - we quote against the specification you actually need rather than the one on the box.
Specifications
| Compliance certificates | CE, Federal Communications Commission (FCC), RoHS |
|---|---|
| Switch type | Managed |
| Ethernet LAN data rates | 10,100,1000,2500 Mbit/s |
| Product colour | Black |
|---|---|
| Rack mounting | Yes |
| Wall mountable | Yes |
| Form factor | Desktop/Wall-Mounting |
| Sustainability compliance | Yes |
|---|
| Quick start guide | Yes |
|---|
| Rate limiting | Yes |
|---|
| Width | 226 mm |
|---|---|
| Depth | 131 mm |
| Height | 35 mm |
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| LED indicators | Yes |
|---|
| Heat dissipation | 614.58 BTU/h |
|---|
| Power over Ethernet plus (PoE+) ports quantity | 8 |
|---|---|
| Total Power over Ethernet (PoE) budget | 160 W |
| Power consumption (max) | 180.1 W |
|---|---|
| Power supply included | Yes |
| Power source | AC |
| Power over Ethernet (PoE) | Yes |
| Multicast support | Yes |
|---|
| DHCP features | DHCP relay, DHCP server, DHCPv6 client, DHCPv6 snooping |
|---|---|
| System event log | Yes |
| IGMP snooping | Yes |
| Authentication | MAC-based authentication, Port-based authentication |
| Authentication type | RADIUS |
| Loop protection | Yes |
| MAC address table | 16000 entries |
|---|---|
| Switching capacity | 80 Gbit/s |
| Forwarding rate | 59.52 Mpps |
| Jumbo frames support | Yes |
| Jumbo frames | 9000 |
| Packet buffer memory | 12 MB |
| 10G support | Yes |
|---|---|
| Static route | Yes |
| VLAN support | Yes |
| Networking standards | IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.3x |
| Port mirroring | Yes |
| Security algorithms | SNMP, SNMPv2, SNMPv3 |
| Flow control support | Yes |
| Link aggregation | Yes |
| Spanning tree protocol | Yes |
| Broadcast storm control | Yes |
| Virtual LAN features | Protocol-based VLAN, Tagged VLAN, Voice VLAN |
| Number of VLANs | 4000 |
| Basic switching RJ-45 Ethernet ports quantity | 8 |
|---|---|
| Basic switching RJ-45 Ethernet ports type | 2.5G Ethernet (100/1000/2500) |
| Installed SFP modules quantity | 0 |
| Installed SFP+ modules quantity | 0 |
| SFP+ module slots quantity | 2 |
| Power connector | DC-in jack |
| Web-based management | Yes |
|---|---|
| Access Control List (ACL) | Yes |
| Switch layer | L2/L2+ |
| Cloud-managed | Yes |
| Quality of Service (QoS) support | Yes |
| Configuring Location Settings (CLI) | Yes |
| ARP inspection | Yes |
| Reset button | Yes |
| MIB support | Y |
Warranty
3 year limited warranty for normal product and 5 year warranty for managed switch
