TP-Link Omada S7500-48XF4C network switch Managed
TP-LinkModel S7500-48XF4C
Image 1 of 5
Available on lead time
Request a quote for pricing
We respond within one business day. Volume pricing available.
Nationwide delivery, installed in Lagos. Lead times Manufacturer warranty, claims handled by us. How it works Authorised reseller, certified by the Standards Organisation of Nigeria. Buying in volume? Send the schedule and we price the whole list.
At a glance
- Switch type
- Managed
- Ethernet LAN data rates
- 1000,10000,40000,100000 Mbit/s
- Management protocols
- SNMPv1/v2c/v3
- Cables included
- AC, LAN (RJ-45)
Overview
TP-Link Omada S7500-48XF4C network switch Managed is a TP-Link switches & adapter with a management protocols of SNMPv1/v2c/v3 and a ethernet lan data rates of 1000,10000,40000,100000 Mbit/s. The details below are drawn from the manufacturer specification and are what to check against your own requirement before requesting a quote.
Management protocols is SNMPv1/v2c/v3. Ethernet LAN data rates is 1000,10000,40000,100000 Mbit/s. Packet buffer memory is 8 MB. Heat dissipation is 295.85 BTU/h. Switch type is Managed. Flow control support is Yes. Link aggregation is Yes. Spanning tree protocol is Yes. Each of these is listed again in the specification table, so nothing here has to be taken on trust.
Warranty: 3 year limited warranty for normal product and 5 year warranty for managed switch. Ask us if you need a different configuration - we quote against the specification you actually need rather than the one on the box.
Specifications
| Switch type | Managed |
|---|---|
| Ethernet LAN data rates | 1000,10000,40000,100000 Mbit/s |
| Management protocols | SNMPv1/v2c/v3 |
|---|
| Cables included | AC, LAN (RJ-45) |
|---|
| Rate limiting | Yes |
|---|
| Width | 440 mm |
|---|---|
| Depth | 380 mm |
| Height | 44 mm |
| Package type | Box |
|---|
| Operating temperature (T-T) | -5 - 40 °C |
|---|---|
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Heat dissipation | 295.85 BTU/h |
|---|
| Web-based management | Yes |
|---|---|
| Cloud-managed | Yes |
| Power consumption (max) | 86.7 W |
|---|---|
| AC input voltage | 110 V |
| AC input frequency | 60 Hz |
| Power supply included | Yes |
| Power source | AC |
| Power over Ethernet (PoE) | No |
| Stackable | Yes |
|---|---|
| Rack mounting | Yes |
| Multicast support | Yes |
|---|
| DHCP features | DHCP client |
|---|
| MAC address table | 128000 entries |
|---|---|
| Switching capacity | 1760 Gbit/s |
| Forwarding rate | 610.1 Mpps |
| Jumbo frames support | Yes |
| Jumbo frames | 9000 |
| Packet buffer memory | 8 MB |
| 10G support | Yes |
|---|---|
| VLAN support | Yes |
| Flow control support | Yes |
| Link aggregation | Yes |
| Spanning tree protocol | Yes |
| Basic switching RJ-45 Ethernet ports type | No |
|---|---|
| SFP+ module slots quantity | 48 |
| USB 2.0 ports quantity | 3 |
| Console port | RJ-45 |
| QSFP28 ports quantity | 4 |
Warranty
3 year limited warranty for normal product and 5 year warranty for managed switch
