TP-Link S5500-4XHPP2XF network switch Managed L2/L2+ Power over Ethernet (PoE) Grey
TP-LinkModel S5500-4XHPP2XF
Image 1 of 5
Available on lead time
Request a quote for pricing
We respond within one business day. Volume pricing available.
Nationwide delivery, installed in Lagos. Lead times Manufacturer warranty, claims handled by us. How it works Authorised reseller, certified by the Standards Organisation of Nigeria. Buying in volume? Send the schedule and we price the whole list.
At a glance
- Compliance certificates
- CE, Federal Communications Commission (FCC), RoHS
- Switch type
- Managed
- Product colour
- Grey
- Rack mounting
- Yes
Overview
TP-Link S5500-4XHPP2XF network switch Managed L2/L2+ Power over Ethernet (PoE) Grey is a TP-Link switches & adapter with a power connector of AC-in jack and a virtual lan features of MAC address-based VLAN, Protocol-based VLAN, Voice VLAN. The details below are drawn from the manufacturer specification and are what to check against your own requirement before requesting a quote.
Power connector is AC-in jack. Virtual LAN features is MAC address-based VLAN, Protocol-based VLAN, Voice VLAN. Packet buffer memory is 16 MB. Compliance certificates is CE, Federal Communications Commission (FCC), RoHS. Heat dissipation is 835.67 BTU/h. Switch type is Managed. Flow control support is Yes. Authentication type is AAA, RADIUS, TACACS+. Each of these is listed again in the specification table, so nothing here has to be taken on trust.
Warranty: 3 year limited warranty for normal product and 5 year warranty for managed switch. Ask us if you need a different configuration - we quote against the specification you actually need rather than the one on the box.
Specifications
| Compliance certificates | CE, Federal Communications Commission (FCC), RoHS |
|---|---|
| Switch type | Managed |
| Product colour | Grey |
|---|---|
| Rack mounting | Yes |
| Rate limiting | Yes |
|---|
| Width | 294 mm |
|---|---|
| Depth | 180 mm |
| Height | 44 mm |
| Operating temperature (T-T) | 0 - 50 °C |
|---|---|
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| LED indicators | Yes |
|---|
| Heat dissipation | 835.67 BTU/h |
|---|
| Power over Ethernet (PoE) ports quantity | 4 |
|---|---|
| Total Power over Ethernet (PoE) budget | 200 W |
| Power consumption (max) | 244.9 W |
|---|---|
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power supply included | Yes |
| Power source | AC |
| Power over Ethernet (PoE) | Yes |
| Multicast support | Yes |
|---|
| DHCP features | DHCP relay, DHCP server |
|---|---|
| System event log | Yes |
| Password protection | Yes |
| IGMP snooping | Yes |
| Authentication type | AAA, RADIUS, TACACS+ |
| SSH/SSL support | Yes |
| Loop protection | Yes |
| Static port security | Yes |
| MAC address table | 32000 entries |
|---|---|
| Switching capacity | 120 Gbit/s |
| Forwarding rate | 89.28 Mpps |
| Number of queues | 8 |
| Number of static routes | 48 |
| Number of IP interfaces | 128 |
| Jumbo frames support | Yes |
| Jumbo frames | 9000 |
| Packet buffer memory | 16 MB |
| 10G support | Yes |
|---|---|
| Static route | Yes |
| Networking standards | IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt |
| Port mirroring | Yes |
| Flow control support | Yes |
| Link aggregation | Yes |
| Spanning tree protocol | Yes |
| Broadcast storm control | Yes |
| Virtual LAN features | MAC address-based VLAN, Protocol-based VLAN, Voice VLAN |
| Basic switching RJ-45 Ethernet ports quantity | 1 |
|---|---|
| Installed SFP modules quantity | 0 |
| Installed SFP+ modules quantity | 0 |
| SFP+ module slots quantity | 2 |
| Console port | RJ-45/Micro-USB |
| Power connector | AC-in jack |
| Web-based management | Yes |
|---|---|
| Access Control List (ACL) | Yes |
| Switch layer | L2/L2+ |
| Quality of Service (QoS) support | Yes |
| Configuring Location Settings (CLI) | Yes |
| Traffic classification | Yes |
Warranty
3 year limited warranty for normal product and 5 year warranty for managed switch
