TP-Link S6500-24MPP4Y network switch Managed L3 2.5G Ethernet (100/1000/2500) Power over Ethernet (PoE) 1U Grey
TP-LinkModel S6500-24MPP4Y
Image 1 of 5
Available on lead time
Request a quote for pricing
We respond within one business day. Volume pricing available.
Nationwide delivery, installed in Lagos. Lead times Manufacturer warranty, claims handled by us. How it works Authorised reseller, certified by the Standards Organisation of Nigeria. Buying in volume? Send the schedule and we price the whole list.
At a glance
- Switch type
- Managed
- Cables included
- AC
- Quick start guide
- Yes
- Rate limiting
- Yes
Overview
TP-Link S6500-24MPP4Y network switch Managed L3 2.5G Ethernet (100/1000/2500) Power over Ethernet (PoE) 1U Grey is a TP-Link switches & adapter with a virtual lan features of MAC address-based VLAN, Protocol-based VLAN, Voice VLAN and a heat dissipation of 5952.2 BTU/h. The details below are drawn from the manufacturer specification and are what to check against your own requirement before requesting a quote.
Virtual LAN features is MAC address-based VLAN, Protocol-based VLAN, Voice VLAN. Heat dissipation is 5952.2 BTU/h. Switch type is Managed. Flow control support is Yes. Authentication type is AAA, RADIUS, TACACS+. SSH/SSL support is Yes. Total Power over Ethernet (PoE) budget is 1440 W. Loop protection is Yes. Each of these is listed again in the specification table, so nothing here has to be taken on trust.
Warranty: 3 year limited warranty for normal product and 5 year warranty for managed switch. Ask us if you need a different configuration - we quote against the specification you actually need rather than the one on the box.
Specifications
| Switch type | Managed |
|---|
| Cables included | AC |
|---|---|
| Quick start guide | Yes |
| Rate limiting | Yes |
|---|
| Width | 440 mm |
|---|---|
| Depth | 420 mm |
| Height | 44 mm |
| Operating temperature (T-T) | -5 - 40 °C |
|---|---|
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage relative humidity (H-H) | 5 - 90% |
| Stackable | Yes |
|---|---|
| Product colour | Grey |
| Number of fans | 4 fan(s) |
| Rack mounting | Yes |
| Form factor | 1U |
| Heat dissipation | 5952.2 BTU/h |
|---|
| Power over Ethernet (PoE) ports quantity | 24 |
|---|---|
| Total Power over Ethernet (PoE) budget | 1440 W |
| Power consumption (max) | 1745.5 W |
|---|---|
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power supply included | Yes |
| Power source | AC |
| Power over Ethernet (PoE) | Yes |
| Multicast support | Yes |
|---|
| DHCP features | DHCP relay, DHCP server, DHCPv6 relay |
|---|---|
| System event log | Yes |
| Password protection | Yes |
| IGMP snooping | Yes |
| Authentication type | AAA, RADIUS, TACACS+ |
| SSH/SSL support | Yes |
| Loop protection | Yes |
| Static port security | Yes |
| MAC address table | 32000 entries |
|---|---|
| Switching capacity | 320 Gbit/s |
| Forwarding rate | 238.1 Mpps |
| Number of queues | 8 |
| Jumbo frames support | Yes |
| Jumbo frames | 9000 |
| 10G support | Yes |
|---|---|
| Static route | Yes |
| Networking standards | IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt |
| Port mirroring | Yes |
| Flow control support | Yes |
| Link aggregation | Yes |
| Spanning tree protocol | Yes |
| Active link detection | Yes |
| Broadcast storm control | Yes |
| Virtual LAN features | MAC address-based VLAN, Protocol-based VLAN, Voice VLAN |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
|---|---|
| Basic switching RJ-45 Ethernet ports type | 2.5G Ethernet (100/1000/2500) |
| Installed SFP modules quantity | 0 |
| Installed SFP+ modules quantity | 0 |
| USB 2.0 ports quantity | 2 |
| Console port | RJ-45/USB Type-C |
| SFP28 ports quantity | 4 |
| Web-based management | Yes |
|---|---|
| Access Control List (ACL) | Yes |
| Switch layer | L3 |
| Cloud-managed | Yes |
| Quality of Service (QoS) support | Yes |
| Configuring Location Settings (CLI) | Yes |
Warranty
3 year limited warranty for normal product and 5 year warranty for managed switch
