TP-Link VIGI C485 Turret IP security camera Outdoor 3840 x 2160 pixels Ceiling
TP-LinkModel VIGIC485_4MM
Image 1 of 5
Available on lead time
Request a quote for pricing
We respond within one business day. Volume pricing available.
Nationwide delivery, installed in Lagos. Lead times Manufacturer warranty, claims handled by us. How it works Authorised reseller, certified by the Standards Organisation of Nigeria. Buying in volume? Send the schedule and we price the whole list.
At a glance
- Mounting kit
- Yes
- Waterproof connector
- Yes
- Ethernet LAN (RJ-45) ports
- 1
- Connectivity technology
- Wired
Overview
TP-Link VIGI C485 Turret IP security camera Outdoor 3840 x 2160 pixels Ceiling is a TP-Link cctv camera with a supported network protocols of TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS and a ethernet lan (rj-45) ports of 1. The details below are drawn from the manufacturer specification and are what to check against your own requirement before requesting a quote.
Supported network protocols is TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS. Ethernet LAN (RJ-45) ports is 1. Number of Privacy masking areas is 4. Maximum memory card size is 512 GB. Noise reduction is Yes. Camera shutter speed is 1/3 to 1/10000. Reset button is Yes. International Protection (IP) code is IP67. Each of these is listed again in the specification table, so nothing here has to be taken on trust.
Warranty: 3 year limited warranty. Ask us if you need a different configuration - we quote against the specification you actually need rather than the one on the box.
Specifications
| Mounting kit | Yes |
|---|---|
| Waterproof connector | Yes |
| Ethernet LAN (RJ-45) ports | 1 |
|---|
| Connectivity technology | Wired |
|---|---|
| Wi-Fi | No |
| Bluetooth | No |
| DC-in jack | Yes |
| Maximum memory card size | 512 GB |
| Reset button | Yes |
|---|
| Width | 111 mm |
|---|---|
| Depth | 111 mm |
| Height | 83.7 mm |
| Weight | 480 g |
| Operating temperature (T-T) | -30 - 60 °C |
|---|---|
| Storage temperature (T-T) | -40 - 60 °C |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Built-in speaker(s) | Yes |
|---|
| Supported graphics resolutions | 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2560 x 1440, 3840 x 2160 |
|---|
| Type | IP security camera |
|---|---|
| Angle of rotation | 360° |
| Placement supported | Outdoor |
| Power consumption (max) | 11.5 W |
|---|---|
| Power source type | DC, PoE |
| Power consumption (Power over Ethernet (PoE)) | 12.5 W |
| DC output voltage | 12 |
| Maximum resolution | 3840 x 2160 pixels |
|---|
| IP address filtering | Yes |
|---|---|
| Password protection | Yes |
| Video motion detection | Yes |
| HTTPS encryption | Yes |
| Human and vehicle targets classification | Yes |
| Built-in HDD | No |
|---|---|
| Compatible memory cards | MicroSD (TransFlash) |
| Ethernet LAN | Yes |
|---|---|
| Live view | Yes |
| Supported network protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS |
| Sample rate | 8 kHz |
|---|---|
| Noise reduction | Yes |
| Audio system | 2-way |
|---|---|
| Built-in microphone | Yes |
| Signal-to-Noise Ratio (SNR) | 52 dB |
| Video compression formats | H.264, H.264+, H.265, H.265+ |
|---|---|
| Frame rate | 25 fps |
| Video streaming | Yes |
| Noise reduction technology | 3D noise reduction |
| Bit rate control | Constant Bit Rate (CBR), Variable Bit Rate (VBR) |
| Back Light Compensation (BLC) | Yes |
| Highlight Compensation (HLC) | Yes |
| Region of Interest (ROI) encoding | Yes |
| Smart IR | Yes |
| Image quality adjustment | Brightness, Contrast, Mirror, Saturation, Sharpness |
| Privacy masking | Yes |
| Night vision | Yes |
|---|---|
| Night vision distance | 30 m |
| LED type | IR/White |
| Number of illumination LEDs | 4 |
| Infra-red wavelength | 850 nm |
| Number of lenses | 1 |
|---|---|
| Detect distance | 107 m |
| Observe distance | 44 m |
| Recognize distance | 21 m |
| Maximum aperture number | 1.6 |
| Identify distance | 11 m |
| Fixed focal length | 4 mm |
| Optical sensor size | 25.4 / 2.7 mm (1 / 2.7") |
|---|---|
| Progressive scan | Yes |
| Minimum illumination | 0.005 lx |
|---|---|
| Total megapixels | 8 MP |
| Lens viewing angle, horizontal | 91.5° |
| Lens viewing angle, vertical | 46.1° |
| Lens viewing angle, diagonal | 109.6° |
| Camera shutter speed | 1/3 to 1/10000 |
| Number of Privacy masking areas | 4 |
| Audio formats supported | G.711 |
|---|---|
| Card reader integrated | Yes |
| Number of cameras | 1 |
| Sensor type | CMOS |
| Wide Dynamic Range (WDR) | Yes |
| Day/night mode | Yes |
| Infrared (IR) cut-off filter | Yes |
| Built-in light | Yes |
| Dynamic range | 120 dB |
| Pan range | 0 - 360° |
|---|---|
| Tilt angle range | 0 - 85° |
| Mounting type | Ceiling |
|---|
| Product colour | White |
|---|---|
| Housing material | Metal |
| Form factor | Turret |
| International Protection (IP) code | IP67 |
Warranty
3 year limited warranty
