DELL PowerEdge R750XS server 480 GB Rack (2U) Intel Xeon Silver 4310 2.1 GHz 32 GB DDR4-SDRAM 1100 W
DellModel PY6Y4
Image 1 of 5
Available on lead time
Request a quote for pricing
We respond within one business day. Volume pricing available.
Nationwide delivery, installed in Lagos. Lead times Manufacturer warranty, claims handled by us. How it works Authorised reseller, certified by the Standards Organisation of Nigeria. Buying in volume? Send the schedule and we price the whole list.
At a glance
- Compatible operating systems
- Canonical Ubuntu Server LTS Citrix Hypervisor Microsoft Windows Server with Hyper-V Red Hat Enterprise Linux SUSE Linux Enterprise Server VMware ESXi
- Packaging content
- Riser Config 1, Half Length, Low Profile,2X NEMA 5-15P to C13 Wall Plug, 125 Volt, 15 AMP, 10 Feet (3m), Power Cord, North America
- Ethernet LAN (RJ-45) ports
- 2
- Total carbon footprint (kg of CO2e)
- 8930
Overview
DELL PowerEdge R750XS server 480 GB Rack (2U) Intel Xeon Silver 4310 2.1 GHz 32 GB DDR4-SDRAM 1100 W is a Dell workstations & server with a ethernet lan (rj-45) ports of 2 and a 80 plus certification of 80 PLUS Titanium. The details below are drawn from the manufacturer specification and are what to check against your own requirement before requesting a quote.
Ethernet LAN (RJ-45) ports is 2. 80 PLUS certification is 80 PLUS Titanium. Total carbon footprint (kg of CO2e) is 8930. Total carbon emissions, standard deviation (kg of CO2e) is 4770. Carbon emissions, manufacturing (kg of CO2e) is 1037.4. Carbon emissions, logistics (kg of CO2e) is 162. Carbon emissions, energy usage (kg of CO2e) is 7700. Carbon emissions, end-of-life (kg of CO2e) is 25.9. Each of these is listed again in the specification table, so nothing here has to be taken on trust.
Warranty: 3 Years Basic Hardware Warranty Repair 5x10 HW-Only 5x10 Next Business Day Onsite-Disti SNS. Ask us if you need a different configuration - we quote against the specification you actually need rather than the one on the box.
Specifications
| Compatible operating systems | Canonical Ubuntu Server LTS Citrix Hypervisor Microsoft Windows Server with Hyper-V Red Hat Enterprise Linux SUSE Linux Enterprise Server VMware ESXi |
|---|---|
| Packaging content | Riser Config 1, Half Length, Low Profile,2X NEMA 5-15P to C13 Wall Plug, 125 Volt, 15 AMP, 10 Feet (3m), Power Cord, North America |
| Ethernet LAN (RJ-45) ports | 2 |
| Total carbon footprint (kg of CO2e) | 8930 |
|---|---|
| Total carbon emissions, standard deviation (kg of CO2e) | 4770 |
| Carbon emissions, manufacturing (kg of CO2e) | 1037.4 |
| Carbon emissions, logistics (kg of CO2e) | 162 |
| Carbon emissions, energy usage (kg of CO2e) | 7700 |
| Carbon emissions, end-of-life (kg of CO2e) | 25.9 |
| PAIA version | 1.3.2, 2022 |
| Ethernet interface type | 10 Gigabit Ethernet |
|---|---|
| Ethernet LAN | Yes |
| Cabling technology | 10/100/1000Base-T(X) |
| Power supply input voltage | 200 - 240 V |
|---|---|
| Redundant power supply (RPS) support | Yes |
| Number of redundant power supplies supported | 2 |
| Number of redundant power supplies installed | 2 |
| Power supply | 1100 W |
| Thermal Design Power (TDP) | 120 W |
| 80 PLUS certification | 80 PLUS Titanium |
| Width | 482 mm |
|---|---|
| Depth | 721.6 mm |
| Height | 86.8 mm |
| Operating temperature (T-T) | 10 - 35 °C |
|---|---|
| Storage temperature (T-T) | -40 - 65 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating altitude | 0 - 3048 m |
| Non-operating altitude | 0 - 12000 m |
| RAID support | Yes |
|---|
| Remote administration | iDRAC9 Datacenter 15G |
|---|---|
| Supported SSD sizes | 2.5" |
| Bytes per sector | 512 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
|---|---|
| USB 2.0 ports quantity | 2 |
| Data transfer rate | 6 Gbit/s |
| Buffered memory type | Registered (buffered) |
|---|---|
| Target workload | Read Intensive (RI) |
| Drive writes per day (DWPD) | 1 |
| PCI Express x4 slots | 1 |
|---|---|
| PCI Express x8 slots | 1 |
| PCI Express x16 slots | 4 |
| Operating system installed | No |
|---|
| Total storage capacity | 480 GB |
|---|---|
| SSD size | 2.5" |
| Number of SSDs supported | 16 |
| Supported RAID controllers | Front PERC H755 Rear Load |
| Number of SSDs installed | 1 |
| SSD capacity | 480 GB |
| SSD interface | SATA III |
| Optical drive type | No |
| Hot-Plug support | Yes |
| Internal memory | 32 GB |
|---|---|
| Memory types supported by processor | DDR4-SDRAM |
| Memory clock speeds supported by processor | 2666 MHz |
| Internal memory type | DDR4-SDRAM |
| Memory layout (slots x size) | 2 x 16 GB |
| Memory slots | 16x DIMM |
| Maximum internal memory | 1 TB |
| Memory ranking | 2 |
| Memory data transfer rate | 3200 MT/s |
| On-board graphics card | No |
|---|---|
| On-board graphics card model | Not available |
| Chassis type | Rack (2U) |
|---|---|
| Product colour | Black |
| Bezel | Yes |
| Processor manufacturer | Intel |
|---|---|
| Processor family | Intel Xeon Silver |
| Processor generation | 3rd Generation Intel® Xeon® Scalable |
| Processor model | 4310 |
| Processor cores | 12 |
| Processor threads | 24 |
| Processor boost frequency | 3.3 GHz |
| Processor frequency | 2.1 GHz |
| System bus rate | 10.4 GT/s |
| Processor cache | 18 MB |
| Number of processors installed | 2 |
Warranty
3 Years Basic Hardware Warranty Repair 5x10 HW-Only 5x10 Next Business Day Onsite-Disti SNS
